Rotary Sensor 5320-series

  • 1 million plus operational cycles
  • IP66 or IP67
  • Extended temperature range
  • High quality, rugged construction
  • Wide range of configurations

Rotary Sensor 5320-series

The 5320 series from Regal Components offers a highly reliable rotary potentiometer sensor that can be easily integrated or repackaged into a wide variety of existing and new applications.

The 5320 series is ideally suited for tight packaging constraints while providing superior durability, long service life and repeatable accuracy. The sensor is fully sealed and impervious to contamination and
moisture. A wide variety of standard and non-standard options are available including detent functions, electrical/mechanical angles, shaft/bushing sizes, lengths and configurations, resistance values, etc.

The 5320 Series standard termination offers gold plated through holes for direct soldering. Options are also available for custom termination methods by contacting Regal Components.

The 5320 series sensors offer all of the advantages of a cost effective, traditional potentiometer while providing a rugged, compact, low-profile design to survive the harshest conditions.



Technical data

Technology Potentiometer
Housing Plastic
Linearity ±2.0% FS
Deflection 240°
Resolution Infinite
Resistance 5 kOhm
Output Voltage divider
Temperature range -40°C…+125°C
Lifetime 1 million cycles
