Regasense® SenseAI Cylinder Sensor RSL51

  • Non-contact technology
  • Compact design
  • Easy to install
  • AI enhanced design

SenseAI Cylinder Sensor RSL51

The SenseAI RSL51 cylinder sensor is the sixth-generation in-cylinder position sensor designed for compact installation in various cylinder applications.

Leveraging many years of experience with cylinder sensors, combined with innovative AI-enhanced design and Hall effect technology, it delivers a robust, reliable, fast, and versatile sensor system.

The sensor chassis comprises of three stainless steel parts welded together to make one homogeneous body capable of an operating pressure of up to 35 MPa. It is mechanically backwards compatible with our PS6500, PS6300 and GYPMR sensor models.

All electronics are integrated into this non-contact sensor; no external electronics for signal processing are required. The sensor features standard components, which ensure component availability and futureproofing.

The distance between the integrated sensor elements is maximized, meaning that fewer components are used. This results in a product saving resources and ensuring high reliability, with reduced potential for errors.

SenseAI is our new brand; it is a platform including products with advanced AI technology.

The SenseAI RSL51 is a part of the Regal Components Regasense® family of compact position sensors.


  • Non-contact technology
  • Compact design
  • Easy to install
  • AI enhanced design



SenseAI RSL51 Product Images Regal Components

Technical Data

Working pressure Max. 350 bar
Technology Hall Effect
Linearity < ±1.0 mm
Repeatability ±0.2 mm typical
Strokes 50… 400 mm
Output 0.5-4.5 VDC
Temperature range -40°C…+105°C
